McQuay AGS 210CS/H User Manual

18 IMM AGS-2
Table 10, Spring Flex Isolators
Dimensions
In. (mm)
Housing
Spring
Color
Max. Load
Each
Lbs. (kg)
Defl.
In. (mm)
A B C D E
Housing
Part Number
Spring
Part Number
CP-2-27 Orange
1500
(681)
0.5
(12.7)
10.2
(259.1)
9.0
(228.6)
7.7
(195.6)
2.7
(68.6)
5.75
(146.0)
226103B-00 (2) 226117A-00
CP-2-28 Green
1800
(815)
0.5
(12.7)
10.2
(259.1)
9.0
(228.6)
7.7
(195.6)
2.7
(68.6)
5.75
(146.0)
226103B-00 (2) 226118A-00
CP-2-31 Gray
2200
(998)
0.5
(12.7)
10.2
(259.1)
9.0
(228.6)
7.7
(195.6)
2.7
(68.6)
5.75
(146.0)
226103B-00 (2) 226119A-00
CP-2-32 White
2600
(1180)
0.5
(12.7)
10.2
(259.1)
9.0
(228.6)
7.7
(195.6)
2.7
(68.6)
5.75
(146.0)
226103B-00 (2) 226120A-00
Table 11, Neoprene-in-Shear Isolators
Dimensions
In. (mm)
Type
Max. Load
Each
Lbs. (kg)
Defl.
In. (mm)
A B C D (1) E H L W
McQuay
Part Number
RP-4 Black
1500
(681)
0.25
(6.4)
3.75
(95.3)
0.5
(12.7)
5.0
(127.0)
0.56
(14.2)
0.25
(6.4)
1.6
(41.1)
6.5
(165.1)
4.6
(116.8)
216398A-04
RP-4 Red
2250
(1019)
0.25
(6.4)
3.75
(95.3)
0.5
(12.7)
5.0
(127.0)
0.56
(14.2)
0.25
(6.4)
1.6
(41.1)
6.5
(165.1)
4.6
(116.8)
216398A-01
RP-4 Green
3300
(1497)
0.25
(6.4)
3.75
(95.3)
0.5
(12.7)
5.0
(127.0)
0.56
(14.2)
0.25
(6.4)
1.6
(41.1)
6.5
(165.1)
4.6
(116.8)
216398A-03
Note (1) "D" is the mounting hole diameter.
Figure 15, Spring Flex Mountings Figure 16, Single Neoprene-in-
Shear Mounting
