McQuay AGS 210CS/H User Manual

IMM AGS-2 31
Figure 22 , Dimensions, AGS 165CS/H –210CS/H
Note: See page 13 for lifting locations, mounting locations, weights and mounting loads.
0.875 (22.2)
KNOCK OUT
( QTY 4 TOTAL)
8.0 (203.2)
6.0 (152.4)
8.5 (215.9)
7.2 (182.9)
31.5
(800.1)
3307127-00-03
" A "
" B "
18.4 (467.4)
" C " VICTAULIC CONNECTION
263.0 (6680.2)
" D "
INLET
OUTLET
POWER ENTRY
FIELD CONTROL
CONNECTION
100.4
(2550.2)
88.5 (2247.9)
POWER
PANEL
POWER
PANEL
Dimensions In (mm)
UNIT
SIZE
" A " " B " " C " " D "
AGS165C
54.9 (1394.5) 92.9 (2359.7) 8 (203.2) 30.1 (764.5)
AGS175C
54.9 (1394.5) 92.9 (2359.7) 8 (203.2) 30.1 (764.5)
AGS195C
54.9 (1394.5) 92.9 (2359.7) 8 (203.2) 30.1 (764.5)
AGS210C
54.9 (1394.5) 92.9 (2359.7) 8 (203.2) 30.1 (764.5)
