McQuay AGS 210CS/H User Manual

IMM AGS-2 57
Table 31, Lifting and Mounting Weights, Aluminum Fins (Remote Evaporator)
Lifting Weights Mounting Weights
L1 & L2 L3 & L4 M1 & M2 M3 & M4 M5 & M6
Operating &
Shipping
Weights
AGS
MODEL
lbs. kg lbs. kg lbs. kg lbs. kg lbs. kg lbs. kg
120
3029 1375 1021 464 1747 793 1488 676 815 370 8100 8100
125
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
130
3029 1375 1021 464 1747 793 1488 676 815 370 8100 8100
135
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
140
3029 1375 1021 464 1747 793 1488 676 815 370 8100 8100
145
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
160
3029 1375 1021 464 1747 793 1488 676 815 370 8100 8100
165
3196 1451 1590 722 2071 940 1741 790 974 442 9571 9571
170
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
175
3196 1451 1590 722 2071 940 1741 790 974 442 9571 9571
180
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
190
3169 1439 1307 593 1910 867 1632 741 935 424 8952 8952
195
3196 1451 1590 722 2071 940 1741 790 974 442 9571 9571
210
3196 1451 1590 722 2071 940 1741 790 974 442 9571 9571
NOTE: Refer to Figure 36.
Table 32, Lifting and Mounting Weights, Copper Fins (Remote Evaporator)
Lifting Weights Mounting Weights
L1 & L2 L3 & L4 M1 & M2 M3 & M4 M5 & M6
Operating &
Shipping
Weights
AGS
MODEL
lbs. kg lbs. kg lbs. kg lbs. kg lbs. kg lbs. kg
120
3348 1520 1340 608 1960 890 1701 772 1028 467 9376 4257
125
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
130
3348 1520 1340 608 1960 890 1701 772 1028 467 9376 4257
135
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
140
3348 1520 1340 608 1960 890 1701 772 1028 467 9376 4257
145
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
160
3348 1520 1340 608 1960 890 1701 772 1028 467 9376 4257
165
3675 1668 2069 939 2390 1085 2060 935 1293 587 11487 5215
170
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
175
3675 1668 2069 939 2390 1085 2060 935 1293 587 11487 5215
180
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
190
3568 1620 1706 775 2176 988 1898 862 1201 545 10548 4789
195
3675 1668 2069 939 2390 1085 2060 935 1293 587 11487 5215
210
3675 1668 2069 939 2390 1085 2060 935 1293 587 11487 5215
NOTE: Refer to Figure 36.
