28 AGZ 030A through 065A IOM 686
Dimensional Data
Figure 17, Dimensions AGZ 030A through 065A
AGZ Center of Gravity Additional Weight
MODEL inch / mm for Units with Copper
Number A B C D E F X Y Z Operating Shipping Fin Coils lb / kg
030AS 86.2
(2189.5)
81.7
(2075.2)
61.6
(1565.3)
22.3
(566.4)
5.3
(133.8)
15.0
(381.0)
43.9
(1115)
40.2
(1021)
35.9
(912)
3425
(1555)
3350
(1520)
445
(200)
030AE 86.2
(2189.5)
81.7
(2075.2)
61.6
(1565.3)
22.3
(566.4)
5.3
(133.8)
15.0
(381.0)
43.9
(1115)
44.6
(1133)
35.9
(912)
3485
(1580)
3410
(1545)
445
(200)
040AS 86.2
(2189.5)
81.7
(2075.2)
61.6
(1565.3)
22.3
(566.4)
5.3
(133.8)
15.0
(381.0)
43.9
(1115)
44.6
(1133)
36.2
(920)
3480
(1580)
3405
(1545)
445
(200)
040AE 86.2
(2189.5)
81.7
(2075.2)
61.6
(1565.3)
22.3
(566.4)
5.3
(133.8)
15.0
(381.0)
43.9
(1115)
44.6
(1133)
36.2
(920)
3535
(1605)
3460
(1570)
445
(200)
045AS 86.2
(2189.5)
81.7
(2075.2)
61.6
(1565.3)
22.3
(566.4)
5.3
(133.8)
15.0
(381.0)
43.9
(1115)
44.6
(1133)
37.4
(950)
3695
(1675)
3620
(1640)
665
(300)
050AS 86.2
(2189.5)
81.7
(2075.2)
60.0
(1524.0)
24.0
(609.6)
4.3
(108.4)
16.0
(406.4)
44.2
(1123)
40.8
(1036)
35.6
(904)
3850
(1745)
3745
(1700)
445
(200)
050AE 86.2
(2189.5)
81.7
(2075.2)
60.0
(1524.0)
24.0
(609.6)
4.3
(108.4)
16.0
(406.4)
44.6
(1133)
41.2
(1046)
37.4
(950)
4010
(1820)
3905
(1770)
665
(300)
055AS 86.2
(2189.5)
81.7
(2075.2)
60.0
(1524.0)
24.0
(609.6)
4.3
(108.4)
16.0
(406.4)
44.6
(1133)
41.2
(1046)
36.4
(925)
4055
(1840)
3950
(1790)
665
(300)
060AS 86.2
(2189.5)
81.7
(2075.2)
60.0
(1524.0)
24.0
(609.6)
4.3
(108.4)
16.0
(406.4)
44.6
(1133)
41.2
(1046)
36.4
(925)
4115
(1865)
4010
(1820)
665
(300)
065AE 96.2
(2443.5)
91.7
(2329.2)
60.0
(1524.0)
24.0
(609.6)
4.3
(108.4)
16.0
(406.4)
44.6
(1133)
41.8
(1062)
38.8
(986)
4295
(1950)
4190
(1900)
830
(375)
