IM 676 37
Figure 9, 110E through 185E Dimensions
ALR EVAPORATOR CENTER OF GRAVITY ISOLATOR LOCATION NUMBER
UNIT "A" CONN. WATER CONNECTIONS X Y R S T OF
SIZE LENGTH SIZE (1) B C E FANS
110E
229 (5817) 6 (152.4) 117.6
(2987)
13.8 (351) 19.5 (495) 106.5
(2705)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 10
120E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 19.5 (495) 106.5
(2705)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 10
130E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 19.5 (495) 107.0
(2718)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 12
135E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 19.5 (495) 105.0
(2667)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 12
140E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 19.5 (495) 108.0
(2743)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 12
145E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 20.5 (521) 103.0
(2616)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 12
150E
229 (5817) 6 (152.4) 118.5
(3010)
12.9 (328) 20.5 (521) 105.0
(2667)
41.7 (1059) 13 (330) 58 (1473) 215 (5461) 12
160E
263 (6680) 6 (152.4) 153.2
(3891)
47.6 (1209) 20.5 (521) 121.0
(3074)
41.7 (1059) 13 (330) 95 (2413) 250 (6350) 14
170E
263 (6680) 6 (152.4) 153.2
(3891)
47.6 (1209) 20.5 (521) 119.0
(3023)
41.7 (1059) 13 (330) 95 (2413) 250 (6350) 14
180E
263 (6680) 6 (152.4) 153.2
(3891)
47.6 (1209) 20.5 (521) 118.0
(2997)
41.7 (1059) 13 (330) 95 (2413) 250 (6350) 14
185E
263 (6680) 6 (152.4) 153.2
(3891)
47.6 (1209) 20.5 (521) 118.0
(2997)
41.7 (1059) 13 (330) 95 (2413) 250 (6350) 14
