6 IM 676
Vibration Isolators
Vibration isolators are recommended for all roof mounted installations or wherever vibration
transmission is a consideration.
Table 1 lists isolator loads and type. Table 2 lists spring isolator part numbers for all unit sizes. See
Dimensional Data beginning on page 36 for dimensions required to secure each isolator to the
mounting surface.
Table 1, Isolator loads and type
ALR ISOLATOR LOADS AND TYPE FOR EACH MOUNTING LOCATION
UNIT R S T
SIZE TYPE LB. KG TYPE LB. KG TYPE LB. KG
032E CP-1-28 669 303 CP-1-28 677 307 CP-1-28 677 307
035E CP-1-28 673 305 CP-1-28 680 308 CP-1-28 680 308
040E CP-1-28 692 314 CP-1-28 699 317 CP-1-28 699 317
045E CP-1-31 804 365 CP-1-31 794 360 CP-1-31 785 356
050E CP-1-31 822 373 CP-1-31 798 362 CP-1-31 800 363
055E CP-1-31 827 375 CP-1-31 819 371 CP-1-31 809 367
060E CP-1-32 850 386 CP-1-32 841 381 CP-1-32 835 379
065E CP-1-32 868 394 CP-1-32 858 389 CP-1-32 848 385
070E CP-1-32 1040 472 CP-1-32 998 453 CP-1-32 912 414
075E CP-1-32 1042 473 CP-1-32 1019 462 CP-1-32 914 415
080E CP-2-28 1110 503 CP-2-28 1122 509 CP-2-31 1296 588
085E CP-2-28 1180 535 CP-2-28 1186 538 CP-2-31 1474 669
090E CP-2-28 1182 536 CP-2-28 1186 538 CP-2-31 1475 669
100E CP-2-28 1193 541 CP-2-28 1214 551 CP-2-31 1508 684
110E CP-2-28 1339 607 CP-2-28 1364 619 CP-2-31 1697 770
120E CP-2-31 1362 618 CP-2-31 1490 676 CP-2-32 1748 793
130E CP-2-31 1492 677 CP-2-32 1570 712 CP-2-32 1838 834
135E CP-2-31 1506 683 CP-2-32 1670 758 CP-2-32 1904 864
140E CP-2-31 1556 706 CP-2-32 1752 795 CP-2-32 1912 867
145E CP-2-31 1572 713 CP-2-32 1680 762 CP-4-27 2093 949
150E CP-2-32 1601 726 CP-2-32 1704 773 CP-4-27 2120 962
160E CP-4-27 1948 884 CP-2-32 1962 890 CP-2-32 1848 838
170E CP-4-27 2052 931 CP-2-32 2002 908 CP-2-32 1849 839
180E CP-4-27 2052 931 CP-2-32 2002 908 CP-2-32 1849 839
185E CP-4-27 2052 931 CP-2-32 2002 908 CP-2-32 1849 839
NOTE: Two of each isolator type is required for a total of six per unit.
Table 2, Spring flex isolator part numbers
Max. Load
TYPE COLOR McQuay Each
Part No. Lb. KG
CP1-25 Red 477927A-25 450 204
CP1-26 Purple 477927A-26 600 272
CP1-27 Orange 477927A-27 750 340
CP1-28 Green 477927A-28 900 408
CP1-31 Gray 477927A-31 1100 499
CP1-32 White 477927A-32 1300 590
CP2-25 Red 477929A-25 900 408
CP2-26 Purple 477929A-26 1200 544
CP2-27 Orange 477929A-27 1500 681
CP2-28 Green 477929A-28 1800 817
CP2-31 Gray 477929A-31 2200 998
CP2-32 White 477929A-32 2600 1180
CP4-26 Purple 580513A-26 2400 1089
CP4-27 Orange 580513A-27 3000 1361
CP4-28 Green 580513A-28 3600 1633
CP4-31 Gray 580513A-31 4400 1996
CP4-32 White 580513A-32 5200 2359
