IM 676 39
Control center layouts ALR 080E through 185E
Figure 13, Left side, 115V control section Figure 14, Right side, high voltage power
section
Note: PB1, PB2, PB3 are used with multiple point power wiring
Figure 15,Recommended field installed unit disconnect location
Note: Mount disconnect on stationary panel so it does not interfere with hinged doors or
with air intake into coil.
Disconnect Switch
9.5"
(241mm)
Min.
Power
Into
Unit
Hinged Doors on
Control Center
To Next Page
