Page 44 IM 781-2
Figure 29. Main Board Layout
LON Port
*LCD Display
Ethernet
Connection
Phone
Connector
COM3 COM4 COM1 COM2 COM5 COM6
Serial Port
LED's
Heartbeat
LED's
Ethernet
LED's
* Not Currently Supported
