Page 94 OM 780-2
To have e-mail addresses John.Smith@aol.com and Jane.Doe@msn.com receive all three CSM alarm categories (Faults,
Problems, Warnings) at all hours, every day of the week, the operator would configure the following;
a) Set Fault 1 E-mail Address To: = John.Smith@aol.com;Jane.Doe@msn.com
b) Set Problem 1 E-mail Address To: = John.Smith@aol.com;Jane.Doe@msn.com
c) Set Warning 1 E-mail Address To: = John.Smith@aol.com;Jane.Doe@msn.com
d) Leave all three Time Range and all three Valid Days inputs at their defaults
Table 24. Configuring BACnet Alarm Notification (Main > Configuration > Alarms)
Name Description
BACnet Alarm Recipient 1
BACnet Alarm Recipient 2
BACnet Alarm Recipient 3
Up to three different BACnet devices can be sent alarm notifications from the CSM. Use these inputs to enter the
Device Instance number of the target BACnet device. The combination of entering the target BACnet device here
and then selecting one of these BACnet Alarm Recipients as the BACnet Recipient (see next table entry) of a
Fault/Problem/Warning alarm type will result in the CSM sending alarm notifications to the BACnet device. Range
= any valid BACnet Device Instance. Default = -1, -1, and –1 (respectively)
Fault 1 – BACnet Recipient
Fault 2 – BACnet Recipient
Fault 3 – BACnet Recipient
Problem 1 – BACnet Recipient
Problem 2 – BACnet Recipient
Problem 3 – BACnet Recipient
Warning 1 – BACnet Recipient
Warning 2 – BACnet Recipient
Warning 3 – BACnet Recipient
Defines the first of three possible target BACnet device to receive CSM Fault alarms. Range = none, Recipient 1,
Recipient 2, Recipient 3. Default = Recipient 1
Defines the second of three possible target BACnet device to receive CSM Fault alarms. Range = none, Recipient
1, Recipient 2, Recipient 3. Default = Recipient 2
Defines the third of three possible target BACnet device to receive CSM Fault alarms. Range = none, Recipient 1,
Recipient 2, Recipient 3. Default = Recipient 3
Defines the first of three possible target BACnet device to receive CSM Problem alarms. Range = none, Recipient
1, Recipient 2, Recipient 3. Default = Recipient 1
Defines the second of three possible target BACnet device to receive CSM Problem alarms. Range = none,
Recipient 1, Recipient 2, Recipient 3. Default = Recipient 2
Defines the third of three possible target BACnet device to receive CSM Problem alarms. Range = none, Recipient
1, Recipient 2, Recipient 3. Default = Recipient 3
Defines the first of three possible target BACnet device to receive CSM Warning alarms. Range = none, Recipient
1, Recipient 2, Recipient 3. Default = Recipient 1
Defines the second of three possible target BACnet device to receive CSM Warning alarms. Range = none,
Recipient 1, Recipient 2, Recipient 3. Default = Recipient 2
Defines the third of three possible target BACnet device to receive CSM Warning alarms. Range = none, Recipient
1, Recipient 2, Recipient 3. Default = Recipient 3
Fault 1 - Process ID
Fault 2 - Process ID
Fault 3 - Process ID
Problem 1 - Process ID
Problem 2 - Process ID
Problem 3 - Process ID
Warning 1 - Process ID
Warning 2 - Process ID
Warning 3 - Process ID
The handle of a process within the recipient device that is to receive the alarm. Use of this property is a local
mater in the BACnet device receiving the alarm. Range = integer. Default = 0
Fault 1 – Time Range
Fault 2 – Time Range
Fault 3 – Time Range
Problem 1 - Time Range
Problem 2 - Time Range
Problem 3 - Time Range
Warning 1 –Time Range
Warning 2 –Time Range
Warning 3 –Time Range
Defines the time period in which routed alarms can be sent as BACnet notifications (on valid days of the week),
using a start time and end time. If you select “Exclusive”, alarms are sent only outside of the defined period.
Range 12:00 AM to 12:00 AM. Default = 12:00 AM to 12:00 AM, Inclusive
