McQuay M5ACV 030 CR

6.2.13 Viewing Defrost Sensor Temperature
The Chiller Panel displays defrost sensor temperature for each compressor in [Defrost Sensor]
in [Display Menu].
Press ESC to exit to [Display Menu]
6.2.14 Viewing Compressor Discharge Temperature
The Chiller Panel displays compressor discharge temperature for each compressor in [Discharge Sensor]
in [Display Menu].
Press ESC to exit to [Display Menu]
33
Discharge Sensor
Comp 1 : 36.5°C
Defrost Sensor
Comp 1 : 12.8°C
