McQuay M5ACV 030 CR User Manual

Selection Pr Selection Pr
Selection Pr Selection Pr
Selection Pr
ocessocess
ocessocess
ocess
Water Pressure Drop VS Flow Rate
Model : M5ACV030CR - Cooling
Model : M5ACV 030CR - Heating
Model : M5ACV055CR - Cooling
Model : M5ACV055CR - Heating
50
Water Flow
m
3
/hr
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
1.26 109.00 26.56 82.44
1.30 108.40 26.59 81.81
1.32 108.20 28.94 79.26
1.36 108.00 31.54 76.46
1.39 107.20 31.39 75.81
1.43 106.00 31.81 74.19
1.49 105.00 32.30 72.70
Water Flow
m
3
/hr
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
1.89 95.00 38.34 56.66
1.80 96.60 35.40 61.20
1.66 101.00 32.45 68.55
1.44 106.00 28.64 77.36
1.12 111.80 18.51 93.29
Water Flow
m
3
/hr
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
1.58 240.00 69.64 170.36
1.97 222.64 67.41 155.23
2.28 207.55 67.18 140.37
2.52 194.34 66.91 127.43
2.68 185.28 67.64 117.64
2.78 180.00 68.11 111.89
2.80 176.98 66.33 110.65
Water Flow
m
3
/hr
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
2.82 175.47 66.10 109.37
2.79 179.25 68.52 110.73
2.73 182.26 67.30 114.96
2.44 200.00 67.98 132.02
1.89 226.42 67.92 158.50
