Sound Data
49
Sound Pressure Level
Overall
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz (dBA)
M5ACV030CR 56 60 59 53 48 43 38 59
M5ACV055CR 60 63 61 56 52 46 42 62
M5ACV075CR 65 65 63 61 57 51 42 65
M5ACV100CR 61 58 57 58 56 53 53 63
M5ACV135CR 66 58 58 62 60 58 52 67
M5ACV210CR 68 68 62 61 59 56 55 67
Microphone position : 1m from each side .
Sound Power Level
Overall
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz (dBA)
M5ACV030CR 67 74 69 64 59 56 48 71
M5ACV055CR 71 73 71 66 63 56 55 72
M5ACV075CR 77 75 74 71 67 61 53 76
M5ACV100CR 76 75 72 72 71 67 68 78
M5ACV135CR 80 73 74 76 75 71 66 81
M5ACV210CR 79 81 73 72 69 66 65 78
M5ACV030CR
M5ACV055CR
M5ACV075CR
M5ACV100CR
M5ACV135CR
M5ACV210CR
Microphone position : 1m from each side
Measuring location (for Sound Pressure Level)Model
Model
1/1 Octave Sound Pressure Level (dB, ref 20µPa)
Model
1/1 Octave Sound Power Level (dB, ref 1pW)
