McQuay M5ACV 030 CR User Manual

Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
2.20 315.00 21.78 293.22
2.60 300.00 31.81 268.19
3.00 285.00 41.17 243.83
3.40 275.00 52.17 222.83
3.80 265.00 65.60 199.40
Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
3.98 260.00 42.46 217.54
4.25 250.00 46.67 203.33
4.40 240.00 45.10 194.90
4.79 235.00 62.30 172.70
4.83 230.00 59.54 170.46
4.86 227.50 59.30 168.20
4.90 225.00 59.07 165.93
Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
6.31 175.00 104.87 70.13
5.90 183.00 82.71 100.29
5.04 225.00 67.72 157.28
4.64 238.55 57.02 181.53
4.24 251.00 47.32 203.68
Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
5.51 254.55 51.25 203.30
5.89 249.09 57.61 191.48
6.10 244.73 60.38 184.35
6.63 236.36 71.16 165.20
6.68 235.40 72.16 163.24
6.73 234.55 73.29 161.26
6.78 232.73 73.47 159.26
Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
8.22 204.82 107.54 97.28
7.65 214.55 91.34 123.21
7.13 226.64 81.24 145.40
6.56 239.55 71.89 167.66
6.01 248.27 60.81 187.46
Water Flow
m
3
/h
r
Pump Head
kPa
System Head
kPa
Available Head Presure
kPa
7.68 280.00 9.63 270.37
8.64 270.00 14.15 255.85
9.60 255.00 19.44 235.56
10.56 245.00 25.52 219.48
11.25 225.00 30.36 194.64
Model : M5ACV075CR - Cooling / Heating
51
Model : M5ACV100CR - Cooling
Model : M5ACV100CR - Heating
Model : M5ACV135CR - Cooling
Model : M5ACV135CR - Heating
Model : M5ACV210CR - Cooling / Heating

McQuay M5ACV 030 CR Specifications

General

Brand	McQuay
Model	M5ACV 030 CR
Category	Chiller
Language	English
