* This product must be branded. Screen saver will be deactivated for brand less panel
6.3 CMOS Reset
• CMOS reset allows user to reset some settings to default value such as:
Password -> 0001
Backlight -> Normal
Buzzer -> ON
Screen Saver -> Disable
Timeout -> 5m
Contrast -> 50%
Brightness -> Medium
Temp Unit -> °C
• Procedures
1. Power OFF the panel
2. Close the jumper JH2 with the provided jumper header
3. Power ON the panel and the LCD panel should display as follow:
4. Remove the jumper header (put the jumper header on 1 pin only), power OFF and then
power ON the panel.
CM OS is reset tin g ……… …
CMOS reset completed !
Ple ase remove JUMPER
and res tart the panel
35
Parameter Value Description
Normal Turn ON backlight for 30s via key press
Always Always ON backlight
ON Enable beeping sound when fault/ alarm occurred
OFF Disable beeping sound when fault/ alarm occurred
Enable Show screen saver when timeout
Disable No screen save
*Timeout 1-30m Timeout for showing screen saver
Contrast 0-100% Adjust the contrast setting for the LCD panel
OFF No backlight
Low, Medium, High Adjust the backlight intensity
°C Display temperature in degree Celsius
°F Display temperature in degree Fahrenheit
Tem p Unit
Backlight
Buzzer
*Screen Saver
Brightness
