McQuay M5ACV 030 CR User Manual

Safety Devies
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
60
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
M5ACV030CR M5ACV055CR
NC NC
OPEN Pa / psi
4140 / 600 4140 / 600
CLOSE Pa / psi
3312 / 480 3312 / 480
NC NC
OPEN Pa / psi 124 / 18 124 / 18
CLOSE Pa / psi 193 / 28 193 / 28
BUILT IN ON BOARD BUILT IN ON BOARD
DIFFERENTIAL PRESSURE SWITCH
YES YES
ANTI-FREEZE PROTECTION SENSOR
YES YES
DISCH. THERMOSTAT SETTING °C / °F
110 / 230 110 / 230
OVER PRESSURE RELIEF VALVE
YES YES
ANTI-FREEZE HEATER ON BPHE
YES YES
YES YES
YES YES
MODEL
SAFETY DEVICE
COMPRESSOR OLP
PHASE PROTECTION
HIGH PRESSURE
SWITCH
LOW PRESSURE
SWITCH
PUMP OLP
TYPE
TYPE
M5ACV075CR
NC
OPEN Pa / psi
4140 / 600
CLOSE Pa / psi
3312 / 480
NC
OPEN Pa / psi
124 / 18
CLOSE Pa / psi
193 / 28
BUILT IN ON BOARD
DIFFERENTIAL PRESSURE SWITCH
YES
ANTI-FREEZE PROTECTION SENSOR
YES
DISCH. THERMOSTAT SETTING °C / °F
110 / 230
OVER PRESSURE RELIEF VALVE
YES
ANTI-FREEZE HEATER ON BPHE
YES
YES
YES
MODEL
SAFETY DEVICE
COMPRESSOR OLP
PHASE PROTECTION
HIGH PRESSURE
SWITCH
LOW PRESSURE
SWITCH
PUMP OLP
TYPE
TYPE
M5ACV100CR M5ACV135CR
NC NC
OPEN Pa / psi
4140 / 600 4140 / 600
CLOSE Pa / psi
3312 / 480 3312 / 480
NC NC
OPEN Pa / psi 124 / 18 124 / 18
CLOSE Pa / psi 193 / 28 193 / 28
DIFFERENTIAL PRESSURE SWITCH
YES YES
ANTI-FREEZE PROTECTION SENSOR
YES YES
DISCH. THERMOSTAT SETTING °C / °F
110 / 230 110 / 230
OVER PRESSURE RELIEF VALVE
YES YES
ANTI-FREEZE HEATER ON BPHE
YES YES
YES YES
YES YES
MODEL
BUILT IN ON BOARD
SAFETY DEVICE
COMPRESSOR OLP
PHASE PROTECTION
HIGH PRESSURE
SWITCH
LOW PRESSURE
SWITCH
PUMP OLP
TYPE
TYPE

McQuay M5ACV 030 CR Specifications

General

Brand	McQuay
Model	M5ACV 030 CR
Category	Chiller
Language	English
