McQuay M5ACV 030 CR

Model : M5ACV100 / 135CR
72
F G
Model A B C D E
Base Leg Hole
M5ACV100CR 1500 900 1245 1190 297.5 307.5 1446
M5ACV135CR 1800 1150 1245 1190 347.5 416 1766
Model H I J K L M
M5ACV100CR 100 265 385 60 200 170
M5ACV135CR 10 265 385 60 200 170
All Dimensions are in mm
1192.2
98.7
0.652
0.471
5.405
0.821
5.426
0.83
0.07
1199.2
1992.5
50.0
50.0
30.0
0.001
3.6871
3.3861
2092.5
1998.4
WATER INLET
WATER OUTLET
SEE DETAIL A
DETAIL A
All Dimensions are in mm
A
C
D
LL
G
K
M
I
J
B
WATER OUTLET
WATER INLET
H
FE
