McQuay MAC040A User Manual

Model : MAC/ M4AC075 ~ 125B/BR
1. ASSY. BASE PAN 13. ASSY. STRUCTURE BACK RIGHT
2. SCROLL COMPRESSOR 14. PLATE. ORIFICE
3. BRACKET BPHE 15. FAN MOTOR
4. ASSY. BPHE 16. BRACKET FAN MOTOR
6. CLAMP TUBE 17. FAN BLADE
7. ASSY. MAIN STRUCTURE FRONT RIGHT 18. FAN GUARD
8. ASSY. MAIN STRUCTURE FRONT LEFT 19. ASSY. CONTROL BOX
9. ASSY. MAIN COIL RIGHT 20. ASSY. FRONT PANEL
10. ASSY. MAIN COIL LEFT 21. SUPPORT HOST BRACKET
11. ASSY. STRUCTURE BACK RIGHT 23. CLAMP BPHE
12. STRUCTURE. COIL
56
