Page #58 background imageLoading...
Page #58 background image
1. ASSY. BASE PAN H 6. ASSY. PANEL SIDE LEFT H
2. ASSY. WATER STORAGE TANK 7. PANEL. FRONT SIDE H
3. ASSY. SUPPORT PILAR H 8. PANEL REAR H
4. ASSY. MAIN STRUCT. FRONT RIGHT 9. PANEL TOP H
5. ASSY. STRUCTURE REAR RIGHT H 10. ASSY. SUPPORT HOISTING BRACKET
57
