OM 200MICRO 15
Menu - Item Group
Figure 13, Menu - Item Group
The keys in this group are used to scroll through the various menus and items presented on the
controller’s display. A menu contains a specific group of items.
Note: When Menu #1 is currently in the display (the first menu in the menu tree-structure), pressing
"PREV." causes an "beginning of menus" message to appear in the display.
Previous Menu
Pressing "PREV." shifts the display to the previous group of items within a menu. Note: When the first
item in a menu is currently in the display, pressing "PREV." causes an "beginning of items" message
to appear in the display.
Next Menu
Pressing "NEXT" shifts the display to the next group of items in a menu. Note: When the last item in
a menu is currently in the display, pressing "NEXT" causes and "end of items" message to appear in
the display.
Previous Item
Pressing "PREV." shifts the display to the previous group of items within a menu. Note: When the
first item in a menu is currently in the display, pressing "PREV." causes an "beginning of items"
message to appear in the display.
Next Item
Pressing "NEXT" shifts the display to the next group of items in a menu. Note: When the last item in
a menu is currently in the display, pressing "NEXT" causes and "end of items" message to appear in
the display.
Action Group
The keys in this group are for making changes to unit control
parameters or for clearing fault conditions.
Note: Before a change to a parameter can be made or before a fault
can be cleared, the display prompts the user with an "Enter
Password" message. At this point, the password must be entered
before the user can continue with the action.
Prev.
Item
Next
Item
Prev.
Menu
Next
Menu
+
Incr.
Help
Clear
Enter
=
Decr.
-
