McQuay PDAA User Manual

IM 934-2 Applied PDAA/PDHA / Page 4 of 44
McQuay Model PDAA/PDHA Product Nomenclature
Note: For Illustration purposes only. Not all options available with all models.
Please consult a McQuay Sales Representative for specic availability.
Damper Type
Damper Control
A = Automatic (Required for Hydronic Heating Subbase)
A = Fresh Air Boost Fan
M = Manual
Y = No Damper
Unit Type
P = PTAC
Product Identier
PDAA = Air Conditioner - Angled Top
PDHA = Heat Pump - Angled Top
Design Series
1 = A Design 1
2 = B Design 2
3 = C Design 3
4 = D Design 4
5 = E Design 5
Unit Size
007 = 7,000
009 = 9,000
012 = 12,000
015 = 15,000
017 = 17,000 (Cooling Only)
Voltage
A = 115-60-1
E = 208/230-60-1
J = 265/277-60-1
P = 208/230-60-1 w/stndy 115-60-1
R = 265-60-1 w/stndy 115-60-1
T = 208/208-60-1
Brand Name
M = McQuay
Refrigerant
A = R-410A
Heating Type
E = Electric Heat
H = Hydronic
A = Hydronic w/Intermediate Electric
Y = None (PDHA only)
Electric Heat
A = 2.5 Kw
B = 3.5 Kw
C = 5.0 Kw
Y = None
Hydronic Heat Type
T = Steam Subbase (Normally Closed)
J = Hot Water Subbase (Normally Open)
Y = None
SKU
A = Stock
B = Build to Order
P DAC 2 009 E M A H A B B M A A E
Controls
Control Board Type
B = Basic Control
P = Premium Controls
(Req'd for Hydronic Heat)
User Interface Type
P = Programmable (Unit Mtd. Touchpad)
A = Programmable with Auto Changeover
(Unit Mtd. Touchpad)
N = Non-Programmable
(Unit Mtd. Touchpad)
Y = None (Wall Stat with Blank-off Plate)
Room Interface
Cabinet Type
B = Angled Top 16" x 42"
Power Connection
L = Long Cord – 72" (Standard)
S - Short Cord – 18" (Optional)
18" Cord, Standard w/Hydronic
Subbase
Y = None
Upgrade Packages
S = Seacoast
Y = None
Warranty
A = Standard
E = Extended
X =Special

McQuay PDAA Specifications

General

Brand	McQuay
Model	PDAA
Category	Air Conditioner
Language	English
