IM 934-2 Applied PDAA/PDHA / Page 6 of 44
Subbase Side Dimension
Electric: 4
3
/
4
" to 13
3
/
4
" (111mm to 349mm) (See Figure 8, page 8)
Hydronic: 0" to 13
3
/
4
" (0mm to 349mm) (See Figure 9, page 9)
Subbase Height Dimension
Electric: 3" to 4" (76mm to 102mm) with 0" to 1" (0mm to 25m) leveling screw
Hydronic: 8" (203mm) with
1
/
4
" (6mm) to 1
1
/
4
" (32mm) leveling bolts
Notes:
1.
Unit pictured with subbase installed. Subbase is optional on 208V and 230V units. Subbase is required on all
265V units and units with hydronic heat. Subbase extends to front edge of unit when furnished with hydronic
heat. Hydronic subbase is ush with the front of the cabinet. Electric subbase is ush with wall sleeve.
2. Subbase side channels are adjustable from 4
3
/
8
" to 13
3
/
4
" (111mm to 349mm).
24" (610mm)
42" (1067mm)
Dimensional Data
13
3
/
4
"
(349mm)
42" (1067mm)
43" (1092mm)
41
1
/
2
" (1054mm)
8
1
/
4
"
(210mm)
3/8" (Stamped) Louver
1
1
/
8
" (Architectural)
17"
(432mm)
16"
(406mm)
8
1
/
4
"
(210mm)
22"
(559mm)
See
Note 1 &2
See Note 1
22
o
1" (25mm)
Figure 3. Chassis Dimensions
Figure 4. Front Panel with Wall Sleeve and Subbase Dimensions
17
19
/
64
" (439mm)
Base Pan
28
5
/
8
" (727mm)
Fin Width
10
1
/
32
"
(255mm)
19
29
/
32
"
(506mm)
5
23
/
32
"
(145mm)
14
1
/
2
"
(368mm)
17
5
/
16
" (440mm)
19
29
/
32
" (506mm)
1/2" (13mm)
Flange Type
