iv
ISOLATOR DIAGRAM
TB1 L/L1 N/L2
N
L1
Power supply 230V / 1Ph-N / 50Hz
5AC/AC020/025 CR
AC TERMINAL BOX
ISOLATOR
E
FUSE
