IM 1068 / Page 3 of 32
Model Nomenclature
Product Style
1= 1st Style Change
SKU
A = Stock
B = Standard Delivery
C = Extended Lead time
Color
I = Antique Ivory
Power Connection
A = Junction Box
Return Air/Outdoor Air
14 = Bottom
Discharge
AR = Flat Top
P KES 2 007 C Z 41 Z 12 AR 14 A I C 1
Product Category
P = PTAC
Product Identier
KES = Type K, Cool Chassis Only
KEI = Type K Cool Chassis Only, IAQ
KEC = Type K Cool Chassis Only,
Corrosion Protection
KHS = Type K Heat Section Only
Design Series
1 = A design
2 = B design
Nominal Capacity - Btuh
007 = 7000
009 = 9000
012 = 12000
019 = 19000
Voltage
A = 115-60-1
C = 208-60-1
G = 230-60-1
J = 277/265-60-1
S = 208-115-60-1
R = 265-115-60-1
Coil Options
Z = None
Heating Options
35 = 2.5 kW nominal
41 = 3.5 kW nominal
44 = 4.0 kW nominal
48 = 5.0 kW nominal
50 = 7.7 kW nominal
62 = Hydronic - Normally Open Valve (Hot Water)
63 = Hydronic - Normally Closed Valve (Steam)
Hand Orientation
A = Same Hand Left
B = Same Hand Right
N = LH Supply / RH Return
P = RH Supply / LH Return
Z = Not Applicable
Model
Controls
12 = Unit Mounted Manual Change Over (MCO)
24 = Unit Mounted Manual Change Over
w/Night Set Back (NSB)
27 = 24V Wall T'stat w/Guest Room Control
(GRC) & Night Set Back (NSB)
32 = 24V Wall T'stat w/Night Set back(NSB)
Note: Availability of voltages, heating options, and controls may vary amongst unit sizes. Consult your McQuay
representative.
