Product Manual WHR-2 21
Table 7, WHR 130EW - WHR 210EW, 60 Hz, IP Units
Entering Condenser Water Temperature (10°F Delta T.)
70°F 80°F 85°F 95°F 105°F
Cap. PWR Cap. PWR Cap. PWR Cap. PWR Cap. PWR
WHR
SIZE
LWT
°F
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
Tons kWi
EER
40.0 133.2 98.4 16.0 126.2 109.7 13.6 122.7 115.5 12.6 115.9 126.5 10.9 108.8 137.5 9.4
42.0 137.9 98.9 16.5 130.9 110.4 14.1 127.2 116.2 13.0 120.3 127.6 11.1 113.0 138.9 9.6
130EW
44.0 143.0 99.1 17.1 135.7 111.0 14.5
132.0 117.0 13.4
124.6 128.8 11.5 116.8 140.2 9.9
46.0 148.0 99.5 17.7 140.4 111.5 14.9 136.8 117.7 13.8 129.2 129.8 11.9 121.7 141.7 10.2
48.0 153.3 99.7 18.2 145.5 112.1 15.3 142.5 118.2 14.5 133.7 130.8 12.1 127.4 142.2 10.5
50.0 158.4 99.8 18.8 150.5 112.6 15.8 146.3 119.0 14.7 138.4 131.7 12.5 130.7 143.3 10.9
40.0 145.3 101.8 17.0 137.7 113.6 14.4 133.8 119.5 13.3 126.4 130.9 11.5 118.7 142.3 9.9
42.0 150.5 102.3 17.5 142.8 114.3 14.9 138.8 120.3 13.8 131.2 132.1 11.8 123.3 143.7 10.2
145EW
44.0 156.0 102.6 18.1 148.0 114.9 15.3
144.0 121.1 14.2
135.9 133.3 12.1 127.4 145.1 10.5
46.0 161.4 102.9 18.7 153.2 115.4 15.8 149.2 121.8 14.6 141.0 134.3 12.6 132.8 146.7 10.8
48.0 167.2 103.2 19.3 158.7 116.0 16.3 155.4 122.3 15.3 145.9 135.4 12.9 139.0 147.2 11.1
50.0 172.8 103.3 20.0 164.2 116.5 16.8 159.6 123.2 15.5 151.0 136.4 13.2 142.6 148.3 11.5
40.0 151.9 109.9 16.4 143.9 122.6 13.9 139.9 129.0 12.9 132.1 141.3 11.1 124.1 153.6 9.6
42.0 157.3 110.4 16.9 149.3 123.4 14.4 145.1 129.8 13.3 137.1 142.6 11.4 128.8 155.1 9.9
155EW
44.0 163.0 110.7 17.5 154.7 124.0 14.8
150.5 130.7 13.7
142.1 143.9 11.7 133.2 156.6 10.1
46.0 168.7 111.1 18.1 160.1 124.6 15.3 155.9 131.5 14.1 147.3 144.9 12.1 138.8 158.3 10.4
48.0 174.7 111.4 18.6 165.9 125.2 15.7 162.5 132.0 14.8 152.5 146.1 12.4 145.2 158.9 10.8
50.0 180.6 111.5 19.2 171.6 125.7 16.2 166.8 132.9 15.0 157.8 147.2 12.7 149.0 160.1 11.1
40.0 164.5 118.8 16.5 155.8 132.5 14.0 151.5 139.5 13.0 143.1 152.7 11.2 134.4 166.0 9.7
42.0 170.3 119.4 17.0 161.7 133.4 14.5 157.1 140.3 13.4 148.5 154.2 11.5 139.5 167.7 9.9
165EW
44.0 176.5 119.7 17.6 167.6 134.1 14.9
163.0 141.3 13.8
153.9 155.6 11.8 144.3 169.3 10.2
46.0 182.7 120.1 18.2 173.4 134.7 15.4 168.9 142.1 14.2 159.6 156.7 12.2 150.3 171.1 10.5
48.0 189.2 120.4 18.8 179.6 135.4 15.8 176.0 142.7 14.9 165.1 158.0 12.5 157.3 171.8 10.8
50.0 195.6 120.5 19.4 185.8 135.9 16.3 180.6 143.7 15.1 171.0 159.1 12.8 161.4 173.1 11.2
40.0 178.6 130.3 16.3 169.2 145.3 13.8 164.5 152.9 12.8 155.4 167.4 11.0 145.9 182.0 9.5
42.0 185.0 130.9 16.7 175.6 146.2 14.3 170.6 153.8 13.2 161.2 169.0 11.3 151.5 183.9 9.8
175EW
44.0 191.7 131.2 17.3 182.0 147.0 14.7
177.0 154.9 13.6
167.1 170.5 11.6 156.6 185.6 10.1
46.0 198.4 131.7 18.0 188.3 147.6 15.2 183.4 155.8 14.0 173.3 171.8 12.0 163.2 187.6 10.3
48.0 205.5 132.0 18.5 195.1 148.4 15.6 191.1 156.4 14.7 179.3 173.2 12.3 170.8 188.3 10.7
50.0 212.4 132.1 19.1 201.8 149.0 16.0 196.1 157.5 14.9 185.6 174.4 12.6 175.2 189.8 11.0
40.0 186.7 130.4 17.0 176.9 145.4 14.4 172.0 153.0 13.3 162.4 167.6 11.5 152.5 182.1 9.9
42.0 193.3 131.0 17.5 183.5 146.3 14.9 178.3 153.9 13.8 168.5 169.1 11.8 158.4 184.0 10.2
185EW
44.0 200.4 131.3 18.1 190.2 147.1 15.3
185.0 155.0 14.2
174.6 170.7 12.1 163.7 185.8 10.5
46.0 207.4 131.8 18.7 196.8 147.7 15.8 191.7 155.9 14.6 181.1 171.9 12.6 170.6 187.7 10.8
48.0 214.8 132.1 19.3 203.9 148.5 16.3 199.7 156.6 15.3 187.4 173.3 12.9 178.5 188.4 11.1
50.0 222.0 132.2 20.0 210.9 149.1 16.8 205.0 157.6 15.5 194.0 174.5 13.2 183.2 189.9 11.5
40.0 198.8 141.4 16.7 188.3 157.7 14.2 183.1 165.9 13.2 173.0 181.7 11.3 162.4 197.5 9.8
42.0 205.9 142.0 17.2 195.4 158.7 14.7 189.9 166.9 13.6 179.5 183.4 11.6 168.6 199.5 10.1
195EW
44.0 213.4 142.4 17.9 202.5 159.5 15.1
197.0 168.1 14.0
186.0 185.1 12.0 174.3 201.5 10.4
46.0 220.8 142.9 18.5 209.6 160.2 15.6 204.1 169.1 14.4 192.9 186.4 12.4 181.6 203.6 10.6
48.0 228.7 143.2 19.0 217.1 161.0 16.0 212.7 169.8 15.1 199.6 187.9 12.7 190.1 204.3 11.0
50.0 236.4 143.4 19.7 224.6 161.7 16.5 218.3 171.0 15.3 206.6 189.3 13.0 195.0 205.9 11.3
40.0 212.9 150.7 16.8 201.7 168.1 14.3 196.1 176.9 13.3 185.3 193.7 11.4 174.0 210.6 9.9
42.0 220.5 151.4 17.3 209.3 169.2 14.8 203.4 177.9 13.7 192.2 195.5 11.7 180.6 212.7 10.2
210EW
44.0 228.5 151.8 18.0 216.9 170.1 15.2
211.0 179.2 14.1
199.2 197.3 12.1 186.7 214.8 10.4
46.0 236.5 152.3 18.6 224.5 170.8 15.7 218.6 180.3 14.5 206.6 198.7 12.5 194.5 217.0 10.7
48.0 245.0 152.7 19.2 232.5 171.7 16.1 227.8 181.0 15.2 213.7 200.3 12.8 203.6 217.8 11.1
50.0 253.2 152.9 19.8 240.5 172.4 16.6 233.8 182.2 15.4 221.3 201.8 13.1 208.9 219.5 11.4
Notes:
1. Bold box areas certified in accordance with ARI Standard 550/590-98.
2. Ratings based on HCFC-22, evaporator fouling of 0.0001, 2.4 gpm/ton; condenser fouling of 0.00025, 3 gpm/ton.
3. For 208V units multiply capacity and EER by 0.98
4. Ratings are based on circuit #1 in lead position and circuit #2 in lag position.
5. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the ratings shown.
6. For LWT of 40°F and below please refer to Application Adjustment Factors section.
