McQuay WHR 017EW

22 Product Manual WHR-2
Table 8, WHR 017EW - WHR 060EW, 60 Hz, SI Units
Entering Condenser Water Temperature (°C)
20°C (68°F) 25°C (77°F) 30°C (86°F) 35°C (95°F) 40°C (104°F)
Cap. PWR Cap. PWR Cap. PWR Cap. PWR Cap. PWR
WHR
SIZE
LWT
°C
kW kWi
COP
kW kWi
COP
kW kWi
COP
kW kWi
COP
kW kWi
COP
5.0 (41.0°F) 64.5 11.4 5.1 61.7 12.7 4.5 58.5 13.9 3.9 54.7 15.0 3.4 52.8 16.3 2.9
6.0 (42.8°F) 66.8 11.5 5.3 63.6 12.8 4.7 60.8 14.1 4.1 56.8 15.2 3.4 54.3 16.5 3.0
017EW
7.0 (44.6°F) 69.1 11.6 5.5 65.3 12.8 4.8 63.1 14.1 4.1 58.8 15.3 3.6 56.5 16.7 3.1
8.0 (46.4°F) 70.2 11.6 5.5 67.0 12.9 4.8 64.0 14.2 4.2 60.8 15.5 3.7 57.6 16.7 3.2
9.0 (48.2°F) 72.8 11.6 5.8 69.4 12.9 5.0 67.7 14.3 4.4 63.1 15.6 3.8 59.7 16.9 3.2
10.0 (50.0°F) 75.1 11.7 6.0 72.0 13.0 5.1 68.5 14.4 4.4 65.4 15.8 3.9 61.9 17.1 3.4
5.0 (41.0°F) 79.1 15.2 4.9 75.6 16.8 4.3 71.7 18.4 3.7 67.1 19.9 3.2 64.7 21.5 2.8
6.0 (42.8°F) 81.9 15.3 5.0 78.0 16.9 4.4 74.5 18.6 3.8 69.6 20.1 3.3 66.6 21.8 2.9
020EW
7.0 (44.6°F) 84.7 15.3 5.2 80.1 17.0 4.5 77.3 18.7 3.9 72.1 20.3 3.4 69.3 22.1 3.0
8.0 (46.4°F) 86.1 15.3 5.3 82.2 17.0 4.6 78.4 18.8 4.0 74.5 20.5 3.5 70.6 22.2 3.0
9.0 (48.2°F) 89.2 15.4 5.5 85.1 17.1 4.7 83.0 18.9 4.1 77.4 20.7 3.6 73.1 22.4 3.1
10.0 (50.0°F) 92.1 15.4 5.7 88.3 17.2 4.9 84.0 19.0 4.2 80.2 20.9 3.7 75.9 22.6 3.2
5.0 (41.0°F) 98.4 19.2 4.8 94.1 21.3 4.1 89.2 23.3 3.6 83.5 25.1 3.1 80.5 27.3 2.7
6.0 (42.8°F) 101.9 19.3 4.9 97.1 21.4 4.3 92.7 23.6 3.7 86.6 25.4 3.2 82.8 27.7 2.8
025EW
7.0 (44.6°F) 105.4 19.4 5.1 99.7 21.5 4.4 96.2 23.7 3.8 89.7 25.7 3.3 86.2 28.0 2.9
8.0 (46.4°F) 107.2 19.4 5.1 102.3 21.6 4.5 97.6 23.8 3.9 92.7 25.9 3.4 87.8 28.1 3.0
9.0 (48.2°F) 111.0 19.5 5.3 105.9 21.7 4.6 103.3 24.0 4.0 96.3 26.2 3.5 91.0 28.3 3.0
10.0 (50.0°F) 114.5 19.6 5.6 109.9 21.8 4.8 104.6 24.1 4.1 99.8 26.5 3.6 94.4 28.6 3.1
5.0 (41.0°F) 110.0 21.2 4.9 105.2 23.6 4.3 99.8 25.8 3.7 93.4 27.8 3.2 90.1 30.2 2.8
6.0 (42.8°F) 113.9 21.4 5.0 108.6 23.7 4.4 103.7 26.1 3.8 96.9 28.1 3.3 92.6 30.6 2.9
030EW
7.0 (44.6°F) 117.8 21.5 5.2 111.5 23.8 4.5 107.6 26.2 3.9 100.3 28.4 3.4 96.4 31.0 3.0
8.0 (46.4°F) 119.9 21.5 5.3 114.4 23.9 4.6 109.1 26.4 4.0 103.7 28.7 3.5 98.2 31.1 3.0
9.0 (48.2°F) 124.2 21.5 5.5 118.4 24.0 4.7 115.5 26.5 4.1 107.7 29.0 3.6 101.8 31.4 3.1
10.0 (50.0°F) 128.1 21.7 5.7 122.9 24.2 4.9 117.0 26.7 4.2 111.6 29.3 3.7 105.6 31.7 3.2
5.0 (41.0°F) 140.1 26.4 5.1 134.7 28.8 4.4 127.7 31.1 4.0 119.8 34.1 3.3 112.9 36.6 3.0
6.0 (42.8°F) 145.4 26.5 5.3 138.3 29.0 4.6 131.1 31.9 4.0 124.2 34.5 3.5 117.3 37.0 3.1
040EW
7.0 (44.6°F) 150.4 26.7 5.4 143.0 29.0 4.7 136.0 32.1 4.1 128.8 34.9 3.6 121.7 37.5 3.2
8.0 (46.4°F) 152.9 26.8 5.5 145.9 29.1 4.8 138.5 32.3 4.2 131.3 35.0 3.7 123.7 37.7 3.2
9.0 (48.2°F) 158.4 26.9 5.7 150.8 29.3 4.9 143.3 32.6 4.3 136.0 35.4 3.7 128.3 38.2 3.3
10.0 (50.0°F) 163.7 27.1 5.9 156.2 29.5 5.1 148.4 32.9 4.4 140.7 35.8 3.8 133.0 38.6 3.3
5.0 (41.0°F) 162.2 29.9 5.2 156.0 32.7 4.5 147.9 35.4 4.1 138.7 38.7 3.4 130.7 41.5 3.1
6.0 (42.8°F) 168.3 30.0 5.4 160.1 32.9 4.7 151.8 36.2 4.1 143.8 39.2 3.6 135.8 42.0 3.1
045EW
7.0 (44.6°F) 174.2 30.3 5.5 165.6 33.0 4.8 157.5 36.5 4.2 149.1 39.6 3.7 140.9 42.6 3.2
8.0 (46.4°F) 177.1 30.4 5.7 168.9 33.1 4.9 160.4 36.7 4.2 152.0 39.8 3.7 143.3 42.8 3.3
9.0 (48.2°F) 183.4 30.6 5.9 174.6 33.3 5.0 165.9 37.0 4.4 157.5 40.2 3.8 148.6 43.4 3.3
10.0 (50.0°F) 189.6 30.7 6.1 180.8 33.5 5.2 171.8 37.4 4.5 162.9 40.6 3.9 154.0 43.9 3.4
5.0 (41.0°F) 189.8 37.5 4.9 182.6 41.0 4.2 173.1 44.3 3.8 162.3 48.5 3.2 153.0 52.0 2.9
6.0 (42.8°F) 197.0 37.6 5.1 187.4 41.2 4.4 177.7 45.3 3.9 168.3 49.1 3.4 158.9 52.7 3.0
050EW
7.0 (44.6°F) 203.9 38.0 5.2 193.9 41.3 4.5 184.4 45.7 3.9 174.6 49.6 3.4 164.9 53.3 3.0
8.0 (46.4°F) 207.3 38.1 5.3 197.7 41.5 4.6 187.7 45.9 4.0 177.9 49.9 3.5 167.7 53.7 3.1
9.0 (48.2°F) 214.7 38.3 5.5 204.4 41.7 4.7 194.2 46.4 4.1 184.4 50.4 3.6 173.9 54.3 3.1
10.0 (50.0°F) 221.9 38.5 5.7 211.6 42.0 4.9 201.1 46.8 4.2 190.7 50.9 3.7 180.3 54.9 3.2
5.0 (41.0°F) 215.6 40.7 5.1 207.4 44.5 4.4 196.7 48.1 4.0 184.4 52.7 3.3 173.8 56.5 3.0
6.0 (42.8°F) 223.8 40.9 5.3 212.9 44.8 4.6 201.9 49.2 4.1 191.1 53.3 3.5 180.5 57.2 3.1
060EW
7.0 (44.6°F) 231.6 41.3 5.4 220.2 44.9 4.7 209.4 49.7 4.1 198.3 53.9 3.6 187.3 57.9 3.2
8.0 (46.4°F) 235.4 41.4 5.6 224.6 45.0 4.8 213.2 49.9 4.2 202.1 54.2 3.7 190.5 58.3 3.2
9.0 (48.2°F) 243.9 41.6 5.8 232.1 45.3 4.9 220.6 50.4 4.3 209.4 54.7 3.7 197.5 59.0 3.3
10.0 (50.0°F) 252.1 41.8 5.9 240.4 45.6 5.1 228.4 50.9 4.4 216.6 55.3 3.9 204.8 59.7 3.3
Notes:
1. Ratings based on HCFC-22, evaporator fouling of 0.0176, 0.043 L/s; condenser fouling of 0.044.
2. For 208V units multiply capacity and COP by 0.98.
3. Ratings are based on circuit #1 in lead position and circuit #2 in lag position.
4. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the ratings shown.
5. For LWT of 5°C and below please refer to Application Adjustment Factors section.
