Product Manual WHR-2 39
Table 22, Single Point Fuse Sizing, WHR 017E - WHR 080E
Recommended Fuse Size(1) Maximum Fuse Size(2)
Single Point Power Single Point Power
w/o Supplemental w/ Supplemental w/o Supplemental
w/
Supplemental
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
Overloads Overloads Overloads Overloads
208 110 - 125 -
017
230 60 110 - 125 -
460 50 - 70 -
575 40 - 50 -
208 125 - 150 -
020
230 60 125 - 150 -
460 70 - 80 -
575 60 - 70 -
208 150 - 175 -
025
230 60 150 - 175 -
460 80 - 90 -
575 70 - 80 -
208 175 - 200 -
030
230 60 175 - 200 -
460 80 - 100 -
575 70 - 80 -
208 175 150 175 150
040
230 60 175 150 175 150
460 90 80 100 80
575 70 60 70 60
208 200 175 225 200
045
230 60 200 175 225 200
460 200 90 110 100
575 90 70 100 80
208 225 225 250 250
050
230 60 225 225 250 250
460 110 100 125 110
575 100 90 110 100
208 250 225 250 250
060
230 60 250 225 250 250
460 125 110 150 125
575 100 90 110 100
208 350 350 350 350
070
230 60 300 300 350 300
460 175 150 175 150
575 110 110 125 125
208 400 350 400 400
080
230 60 350 300 400 350
460 175 150 200 175
575 125 125 150 125
NOTES:
1. "Recommended Fuse Size" are selected at approximately 150% of the largest compressor RLA, plus 100% of all other
loads in the circuit.
2. "Maximum Fuse Sizes" are selected at approximately 225% of the largest compressor RLA, plus 100% of all other loads
in the circuit.
3. Supplemental overloads are used in conjunction with standard inherent overload protection. The supplemental overloads:
• Reduce wire sizing amps
• Add additional protection
• Lower compressor amperage
