40 Product Manual WHR-2
Table 23, Single Point Fuse Sizing, WHR 085E - WHR 145E
Recommended Fuse Size(1) Maximum Fuse Size(2)
Single Point Power Single Point Power
w/o Supplemental w/ Supplemental w/o Supplemental
w/
Supplemental
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
Overloads Overloads Overloads Overloads
208 450 400 500 450
085
230 60 400 400 450 400
460 200 200 225 200
575 175 150 200 175
208 450 400 500 450
090
230 60 450 400 500 450
460 225 200 250 225
575 175 150 200 175
208 400 350 400 350
095
230 60 400 350 400 350
460 200 175 200 175
575 175 150 175 150
208 450 350 450 350
100
230 60 450 350 450 350
460 225 175 225 175
575 175 150 175 150
208 500 450 500 450
110 230 60 450 400 500 400
460 225 200 250 225
575 175 175 175 175
208 500 450 500 450
115
230 60 450 400 500 400
460 250 200 250 225
575 175 175 175 175
208 500 500 500 500
120
230 60 500 450 500 450
460 250 225 250 225
575 200 175 200 175
208 600 600 600 600
130 230 60 500 500 500 500
460 300 250 300 250
575 200 200 200 200
208 600 600 600 600
145 230 60 600 500 600 500
460 300 250 300 250
575 225 200 225 200
NOTES:
1. "Recommended Fuse Size" are selected at approximately 150% of the largest compressor RLA, plus 100%
of all other loads in the circuit.
2. "Maximum Fuse Sizes" are selected at approximately 225% of the largest compressor RLA, plus 100% of all
other loads in the circuit.
