Table 24, Single Point Fuse Size, WHR 155E - WHR 210E
Recommended Fuse Size(1) Maximum Fuse Size(2)
Single Point Power Single Point Power
w/o Supplemental w/ Supplemental w/o Supplemental
w/
Supplemental
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
Overloads Overloads Overloads Overloads
208 700 600 700 600
155
230 60 600 500 600 500
460 300 250 300 250
575 225 200 250 225
208 700 700 700 700
165
230 60 700 600 700 600
460 350 300 350 300
575 300 250 300 250
208 800 800 800 800
175
230 60 800 700 800 700
460 400 350 400 350
575 300 300 300 300
208 800 700 800 700
185
230 60 800 700 800 700
460 400 350 400 350
575 350 300 350 300
208 800 800 800 800
195
230 60 800 800 800 800
460 400 400 450 400
575 350 300 350 300
208 1000 800 1000 800
210
230 60 1000 800 1000 800
460 450 450 450 450
575 350 350 350 350
NOTES:
1. "Recommended Fuse Size" are selected at approximately 150% of the largest compressor RLA, plus 100%
of all other loads in the circuit.
2. "Maximum Fuse Sizes" are selected at approximately 225% of the largest compressor RLA, plus 100% of all
other loads in the circuit.
