42 Product Manual WHR-2
Table 25, Multiple-Point Fuse Sizing, WHR 040E - WHR 145E
Recommended Fuse Size(1)
Multiple Point Power
Maximum Fuse Size(2)
Multiple Point Power
Circuit 1 Circuit 2 Circuit 1 Circuit 2
Unit
Size
Voltage
3-Phase
Freq.
(Hz)
w/o
Supplemental
Overloads
w/
Supplemental
Overloads
w/o
Supplemental
Overloads
w/
Supplemental
Overloads
w/o
Supplemental
Overloads
w/
Supplemental
Overloads
w/o
Supplemental
Overloads
w/
Supplemental
Overloads
208 110 90 110 100 125 100 125 110
040 230 60 110 90 110 100 125 100 125 110
460 60 45 60 50 70 50 70 60
208 125 150 125 150 150 125 150 125
045 230 60 125 150 125 150 150 125 150 125
460 70 80 70 80 80 70 80 70
575 60 70 60 70 70 50 70 50
208 150 125 150 125 175 150 175 150
050 230 60 150 125 150 125 175 150 175 150
460 80 70 80 70 90 80 90 80
575 70 60 70 60 80 70 80 70
208 150 125 150 150 175 150 200 175
060 230 60 150 125 150 150 175 150 200 175
460 80 70 90 80 90 80 100 90
575 70 60 70 60 80 70 80 70
208 225 200 225 200 250 250 250 250
070 230 60 225 175 225 175 250 225 250 225
460 110 90 110 90 125 110 125 110
575 80 70 80 70 90 90 90 90
208 225 225 225 225 300 250 300 250
080 230 60 225 200 225 200 250 225 250 225
460 110 100 110 100 125 110 125 110
575 90 80 90 80 100 90 100 90
208 250 225 300 250 300 250 350 300
085 230 60 225 200 300 250 250 225 350 300
460 110 100 150 125 125 110 175 150
575 90 80 125 100 100 90 150 125
208 300 250 300 250 350 300 350 300
090 230 60 300 250 300 250 350 300 350 300
460 150 125 150 125 175 150 175 150
575 125 100 125 100 150 125 150 125
208 225 200 225 200 250 225 250 225
095 230 60 225 200 225 200 250 225 250 225
460 110 100 110 100 125 110 125 110
575 100 80 100 80 110 90 110 90
208 225 200 225 200 250 250 250 250
100 230 60 225 200 225 200 250 250 250 250
460 110 100 110 100 125 125 125 125
575 90 90 90 90 110 100 110 100
208 300 250 300 250 300 300 300 300
110 230 60 250 225 250 225 300 250 300 250
460 150 110 150 110 150 125 150 125
575 100 90 100 90 125 110 125 110
208 300 250 300 250 300 300 300 300
115 230 60 350 225 250 225 300 250 300 250
460 150 110 150 110 150 125 150 125
575 100 90 100 90 125 110 125 110
208 300 250 350 300 300 300 350 350
230 60 250 225 300 250 300 250 350 300
120 460 150 110 175 125 150 125 175 150
575 110 90 110 110 125 110 125 125
208 350 300 350 300 350 350 350 350
130 230 60 300 250 300 250 350 300 350 300
460 175 125 175 125 175 150 175 150
575 110 110 110 110 125 125 125 125
208 350 300 400 350 350 350 400 350
145 230 60 300 250 350 300 350 300 350 300
460 175 125 175 150 175 150 175 150
575 110 110 110 110 125 125 125 125
NOTES: 1. "Recommended Fuse Size" are selected at approximately 150% of the largest compressor RLA, plus 100% of all other circuit loads.
2. "Maximum Fuse Sizes" are selected at approximately 225% of the largest compressor RLA, plus 100% of all other loads.
