Kitchen
To extend the kitchen from the caravan, press down the blue slide tab, raise the pad bolt and pull kitchen out.
The kitchen will lock into place when extended. To put kitchen away, again press down the blue tabs and push
back into place.
Always install the support leg when the kitchen is extended per diagram 2
Diag: 2
To connect the gas, plug the hose into the gas bayonet as per the diagram below.
CAUTION –
Use of the slide out kitchen cooktop
without the annex or awning may adversely affect
the safety and operation of the appliance.
