I-4 MDS 4710B/9710B I/O Guide MDS 05-3316A01, Rev. E
illustration 1
installation 5–12
LED status indicators 13
meaning of model number code 3–4
mounting 8
operation 12–15
power supply 8
programming 15–17
specifications 34–35
troubleshooting 31–34
Minimizing power consumption using Sleep Mode 7
MODEL command 26
Model number code
description
3
display (MODEL command) 26
Modem
set signal type and modulation mode (MODEM command)
26
types and speeds 10
MODEM command 26
Mounting. See Installation 8
Multiple Address System 1
described by keying behavior of master station 1
N
Network-wide diagnostics
enable/disable internal RTU (RTU command)
28
NOT AVAILABLE error message 19
NOT PROGRAMMED error message 18
O
Operating commands. See Commands
Operating environment specifications
35
Operation
initial start-up
12
reading LED status indicators 13
Order numbers. See Model number codes
Output, 9.9 Vdc Regulated, interface connection for (Pin 19)
12
OWM command 27
OWN command 27
P
PASSWORD INVALID error message 19
PC
connecting to radio for diagnostics/configuration
37
using diagnostic software on 37
Performance testing 38
Pinouts, interface connector 10
Point-to-point system 2
Port, display active (SHOW command) 29
Power
accessory, interface connection for (Pin 18)
12
decrease transmit (DECP command) 23
decrease transmit by 1% (DP command) 24
display RF output (SHOW command) 29
increase transmit (INCP command) 25
increase transmit by 1% (IP command) 26
input, transceiver 8
minimizing use of 7
PWR command 27
PWR LED 13
specifications 35
Problem solving. See Troubleshooting 31
Procedures
checking for alarms
32
connecting a PC to the radio 37
connecting HHT to radio 16
enabling sleep mode 7
general, for entering commands using HHT 18
helical filter adjustment 35
initial start-up 12
installation steps 6
programming operating frequencies 6
re-initializing HHT 17
remotely resetting RTU using InSite software 14
upgrading radio’s software 37
Product
description, MDS 9810/9820 1
numbers. See Model number codes
Programming
15–17
connecting a PC to the radio for 37
updating radio’s software 37
using PC software 37
PTT command 27
interface connection for (Pin 14) 11
interface connection for (Pin 16) 12
PWR command 27
PWR LED 13
R
Radio Inhibit, interface connection for (Pin 12) 11
Radio software. See Software
Receive Audio Output, interface connection for (Pin 11)
11
Received signal strength. See RSSI
Receiver
set audio level (RXLEVEL command)
28
specifications 35
Remote maintenance 15
diagnostic mode 15
resetting RTU 14
REMOTE Radio Diagnostics Software (for transceiver
programming)
15
Remote RTU Reset line, interface connection for (Pin 15) 12
Resetting
Hand-Held Terminal (HHT) 17
RTU remotely 14
RF power, chart for converting to watts or volts 39
RMIS command 27
RMOV command 27
RMRD command 28
RMST command 28
RSSI
checking with DC voltmeter
14
command 28
