DC30D GENSET CONTROLLER USER MANUAL
18
Stop Failure With Pressure Alarm
When the controller detects that the Oil Pressure is not "0" after the execution of the
shutdown, the alarm of stop failure is reported. "ALARM" lights flicker,and displays
"Stop fail-OP" on the LCD screen.
Parameter setting
Please set the parameters according to below steps:
1）In the stop mode, please and simultaneously, then loose so that
you can come to configuration mode.
2）Select the “Set Parameters” menu and press ,then you can come to enter
password interface,the default password is “07623”.
3）Under the parameter browsing interface,press to shift up the parameters,
press to shift down the parameters, press to get into parameter changing
page.
4）Under the parameter modification interface, Press to add number 1, press
to reduce number 1, press to turn the digit into right and done.
5）Under the parameter modification interface, Press to cancer parameter
modification and return to parameter browsing interface.
6）Under the parameter browsing interface,Press to save the parameters and
exit from edition page.
Revert back to default: input password “97011” when coming into parameters
setting, then all the parameters can be set as defaults.
Note: the data can not be saved if the user didn’t press STOP to confirm the
setting.
Parameter list.
1) Basic setting
When the flywheel teeth is set as 0,the RPM
will be resulted by frequency.
Pole 2: 50Hz---3000RPM.Pole 4: 50Hz---
1500RPM.
Pole 6: 50Hz---1000RPM.Pole 8: 50Hz---
750RPM
Disable
1 phase 2 wire
2 phase 3 wire
3 phase 3 wire
3 phase 4 wire
Gens phases:
No gens parameters can be displayed if setting
as disable, which is applied to water pump
genset.
1P1W: Power*1. 2P3W: Power*2.
To Next Page
