DC30D GENSET CONTROLLER USER MANUAL
22
regarded as under battery voltage warn value.When the
battery input is lower than the warning value and comes
into under battery voltage delay but still lower (normal
faults delay), then under battery voltage warns. if the
value is set as 0, then the under battery voltage is
disabled.
4)Generator alarm parameters
Rated frequency multiplying by this value is regarded
as under over frequency alarm value. When the Freq
is higher than the value and comes into over freq
delay but still higher (emergency faults delay), then
over frequency alarms.If the value is set as 200, then
the alarm is disabled.
Rated frequency multiplying by this value is regarded
as under frequency alarm value. When the Freq is
lower than the value and comes into under freq delay
but still lower (normal faults delay), then under
frequency alarms.If the value is set as 0, then the
alarm is disabled.
Rated voltage multiplying by this value is regarded as
over voltage alarm value. When the voltage is higher
than the value and comes into over voltage delay but
still higher (normal faults delay), then over voltage
alarms.If the value is set as 200, then the alarm is
disabled.
Rated voltage multiplying by this value is regarded as
under voltage alarm value. When the voltage is lower
than the value and comes into under voltage delay but
still lower (normal faults delay), then under voltage
alarms.If the value is set as 0, then the alarm is
disabled.
Rated current multiplying by this value is regarded as
over current alarm value. When the current is higher
than the value and comes into over current delay but
still higher (over current faults delay), then over
current alarms.If the value is set as 200, then the
alarm is disabled.
5)Output/input setting
Programmabl
e output 1
（Functional
of PIN 15）
0-11( 7. Idle
speed control)
0. Disable.
1. Public warning output: when there is any warning
output.
2. Public alarm output: when there is any alarm
output, alarm locks till revert back.
