DC30D GENSET CONTROLLER USER MANUAL
23
3. Preheat mode 1: preheat before start.
4.
Fuel output: output once gens starts and off till
stable.
5.
Crank output: output once cranking.
6. Choke control: choke will be started after crank
success and off after delay.
7. Idle speed control: used for speed controller, there
is no output under idle but output under high speed.
8. Gens load: there is continuous output once the
conditions can be meet, which can control the switch
with load.
9.
High speed control: The output is valid after idle
delay is completed, and the output is invalid after
high-speed heat dissipation.
10.Fan Control: used to control radiator electrical fan.
there is output when the preset temperature is higher
than " Temperature for Fan open" and no output
when the preset temperature is lower than
"Temperature for Fan close".
11. E.S.T. hold: shutdown output, it is used for gens
with stop solenoid. when the setting value of
shutdown delay is over, then it is off.
e output 2
（Functional
of PIN 16）
(12. E.S.T. hold)
3
Programmabl
e output 3
（Functional
of PIN 17）
0-11(2.Public
alarm output)
4
Programmabl
e input 1
（Functional
of PIN 6）
0-10(1. Remote
start)
0.Disable.
1.Remote start switch input.
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
7.External instant warning input.
8.External instant alarm input.
9.High temperature cooling and Stop Input : When
the signal is valid and the generator is in normal
operation, if there is a high temperature alarm, the
controller will stop the generator after high-speed heat
dissipation delay; when the signal is invalid, if there is
a high temperature alarm, the controller will stop
directly.
10.Reserve for switching input
5
Programmabl
e input 2
（Functional
of PIN 7）
0-21
(0. Disable)
0.Disable.
1.Remote start switch input.
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
