DC32D GENSET CONTROLLER USER MANUAL
7
 Mains Frequency Hz
4. Protection
 Over speed
 Under speed
 Low oil pressure
 High temperature
 Low fuel level
 External emergency alarm
 Sensor Open
 Over Frequency
 Under Frequency
 Over voltage
 Under voltage
 Maintenance expire
 Low water level alarm
 Crank failure
 Stop Failure
 Over battery voltage
 Under Battery voltage
5. Parameters
Options
Parameters
Operation Voltage
DC8-36V Continuous
Power Consumption
Standby：24V：MAX 1W
Working：24V：MAX 2W
AC Voltage Input
1P2W(L-N input) 30VAC-360VAC(ph-N)
Rotate speed sensor
Frequency
50-9000Hz
Generator Frequency input
50/60Hz
MAX Accumulating Time
9999.9Hours（Min Store time:6min）
Fuel Relay Output
MAX 1Amp DC+VE Supply voltage
Start Relay Output
MAX 1Amp DC+VE Supply voltage
AUX. Output 1
MAX 1Amp DC+VE Supply voltage
Gens Close Output
MAX 10Amp AC(ph-N) Output
Mains Close Output
MAX 10Amp AC(ph-N) Output
Switch value input
Available if connecting with Battery -
Insulation strength
Apply AC2.2kV voltage between high voltage terminal
and low voltage terminal; The leakage current is not
more than 3mA within 1min.
Working condition
-25-65℃
Storage condition
-40-85℃
Protection Level
IP65：when waterproof rubber gasket is added between
controller and its panel
Overall dimension
106mm×86mm×45mm
