Page 178 Speed Level Series - Service & Parts Manual
January 2019Section 10 - Schematics
3084ES - Upper Controls Components
ART_3288
MODE SELECT
91843
LIFT
DRIVE
HIGH SPEED
MID RANGE
HIGH TORQUE
Toggle Switches
EMERGENCY STOP
TILT Light
HORN Button (Optional)
AUTO LEVEL
MANUAL LEVEL
(Front to Rear)
MANUAL LEVEL
(Side to Side)
Forward/Down
Rocker Switch
Potentiometer
Reverse/Up
Rocker Switch
Enable Switch
Micro-Switch
Steer Left
Matrix Module
Cable Connector
OFF / RUN
Steer Right
Toggle Switches
Micro-Switch
3084ES ANSI
ART_3289
91843
91859
LIFT
DRIVE
HIGH SPEED
MID RANGE
HIGH TORQUE
Toggle Switches
EMERGENCY STOP
OVERLOAD
INDICATOR
HORN Button (Optional)
AUTO LEVEL
MANUAL LEVEL
(Front to Rear)
MANUAL LEVEL
(Side to Side)
Forward/Down
Rocker Switch
Potentiometer
Reverse/Up
Rocker Switch
Enable Switch
Micro-Switches
Steer Left
Matrix Module
Cable Connector
OFF / RUN
Steer Right
Toggle Switches
Micro-Switches
Overload Alarm
3084ES CE
