Page 4 Micro 26 - Operator’s Manual
March 2019
Specifications
Working Height* 32 ft 9.45 m
Platform Height 26 ft 7.62 m
Stowed Height
Top Guardrail 90.3 in 2.3 m
Rails Folded 78.75 in 2 m
Platform Floor 47 in 1.2 m
Guardrail Height 43.5 in 1.1 m
Toeboard Height 6 in 0.15 m
Ground Clearance (Stowed) 3 in 7.62 cm
Length-Stowed
Overall 74 in 1.88 m
Ladder Removed 68 in 1.73 m
Chassis Width 31.9 in .81 m
Platform Length
Extended 103.5 in 2.63 m
Retracted 68 in 1.73 m
Roll-Out Deck Length 35.5 in 0.9 m
Platform Width (Outside) 29.1 in .74 m
Wheelbase 55 in 1.4 m
Total Lift Capacity 500 lbs 227 kg
Personnel Capacity 2
Roll-Out Deck Capacity 250 lbs 113 kg
Raise/Lower Speed 30/25 sec
Drive Speed
Stowed 2.5 mph 4 km/h
Elevated .5 mph .8 km/h
Gradeability 25% 14 degrees
Wind Rating Indoor Only
Turning Radius (Inside) 6 in 15 cm
Weight** 4190 lbs 1900 kg
Power Source 24 V DC, 240 Ah Battery Pack
Controls Proportional
Tires 12 in x 5 in 30 cm x 12.5 cm
*Metric equivalent of working height adds 2m to platform height. U.S. adds 6 ft. to platform height.
**Weight may vary with certain options or configurations.
Meets or exceeds the requirements of ANSI A92.20-2018 and CSA B354.6.17.
Section 3 - Specifications
