Medela Basic 30 - Vacuum Adjustment and Device Shutdown

18 | Operating instructions
CAUTIONS
When the Basic 30 is used for wound drainage, the negative pressure should be set
according to instruction of the specialist and not cause any wound damage.
Changing
vacuum level
1. 1.1 Clamp patient tubing
1.2 Turn vacuum regulator to
select the correct vacuum
according to the particular
application.
1.3 Check vacuum gauge for
setting.
7.3
2. 2.1 Disconnect the mains plug
from the fixed mains
socket.
3. Clean and desinfect the Basic 30. See chapter 14.
Placing out of
operation after use
1. 1.1 Press on/off switch to
switch off the Basic 30.
7.4
