20 | Changing reusable jar | Changing disposable liner
9 Changing reusable jar
WARNINGS
Disposable liners are not intended to be reprocessed. Reprocessing could cause loss
of mechanical, chemical and / or biological characteristics.
10 Changing disposable liner
3. Empty jar and dispose of patient tubing according in accor-
dance with local guidelines and inhouse guidelines.
2. 2.1 Prepare new jar and
unpack it.
2.2 Secure new jar in the
clampholder or directly to
the Basic 30
2.3 Reconnect vacuum tubing
and new patient tubing
firmly.
1. 1.1 Switch pump off by
pressing the on/off switch.
1.2 Remove patient and
vacuum tubings from
the lid.
1.3 Remove full jar from the
Basic 30.
1. 1.1 Remove patient tubing
with coloured angle piece
from lid.
1.2 Plug patient port.
4. 4.1 Switch pump on by
pressing the on/off switch.
Vacuum is built up.
4.2 Set vacuum according to
the particular application.
See chapter 7.3.
1.5 l 2.5 l
