EMC
Technical documentation (EMC) | 383
Electromagnetic Immunity
Basic 30 is intended for use in the electromagnetic environment specified below.
The customer or the user of Basic 30 should assure that they are used in such
environment.
Immunity Tests
Electrostatic
Discharge (ESD)
IEC 61000-4-2
IEC 60601
test level
± 6 kV contact
± 8 kV air
Compliance
level
± 6 kV contact
± 8 kV air
Electromagnetic
environment – guidance
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV
for power
supply lines
± 1 kV
for input /
output lines
± 2 kV
for power
supply lines
± 1 kV
for input /
output lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
Voltage dips,
short interrup-
tions and voltage
variations on
power supply
input lines
IEC 61000-4-11
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
± 1 kV
differential mode
± 2 kV
common mode
<5 % U
t
(>95 % dip in U
t
)
for 0.5 cycle
40 % U
t
(60 % dip in U
t
)
for 5 cycles
70 % U
t
(30 % dip in U
t
)
for 25 cycles
<5 % U
t
(>95 % dip in U
t
)
for 5 sec
3 A/m
± 1 kV
differential mode
± 2 kV
common mode
<5 % U
t
(>95 % dip in U
t
)
for 0.5 cycle
40 % U
t
(60 % dip in U
t
)
for 5 cycles
70 % U
t
(30 % dip in U
t
)
for 25 cycles
<5 % U
t
(>95 % dip in U
t
)
for 5 sec
30 A/m
Mains power quality should be that
of a typical commercial or hospital
environment.
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of Basic 30
requires continued operation during
power mains interruptions, it is recom-
mended that Basic 30 be powered
from an uninterruptible power supply
or a battery.
Power frequency magnetic fields
should be at levels of a typical com-
mercial or hospital environment.
