RX8000 Integrated Receiver/Decoders
1553-FGB 101 759 Uen K
www.mediakind.com
Use the (Forward) and (Back) keys to toggle between Direct Frequency and Auto Tune. Use the
(Up) and (Down) keys to toggle between the Enabled and Disabled options.
3.10.7.7.4. Input
This parameter will indicate if the receiver is locked to the 8VSB signal or not. To access this menu
from the above menu, press the (Forward) key.
INPUT |NO TS LOCK
3.1 | >
3.10.7.7.5. 8VSB Signal Level
To further indicate the health status of the incoming the signal the receiver will provide an
estimation of the Signal to Noise ratio of the 8VSB signal.
To access this menu from the above menu, press the (Down) key.
8VSB |CHANNEL 61 SNR 0.00dB
3.2 |FREQUENCY 755.000 MHz
Use the (Up) and (Down) keys to select the required number.
3.10.7.8. Additional Notes
3.10.7.8.1. Regions Using ATSC 8VSB Transmission
The ATSC transmission scheme was developed and deployed in the USA. The ATSC transmission
scheme has since been deployed in Canada and Korea.
An alternative digital terrestrial transmission standard has been developed by the European DVB
standards organization called DVB-T which uses OFDM technology. MediaKind offers an input option
for DVB-T reception in the RX8200 Advanced Modular Receiver.
3.11. Conditional Access
3.11.1. General CA Status
Figure 3-87 CA Service Status Web Page
