MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 11 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
2.1 E2PROM layout version # (02h)
Value
Description
0 Version 0.
1 ~ 255 Invalid version. Treat as version 0.
2.2 WiFi External Component Setting (0x25)
Offset Field Description
25h
4:0
Reserved.
7:5
000: No external RF component GPIO ( iPAiLNA )
010 : Support external RF component GPIO (ePAeLNA)
110 : Internal PA 3 antenna mode for WIFI BT combo chip
External component GPIO usage will need to co-setting with 0x35 and 0x36.
2.3 NIC Configuration 0 (0x34/0x35)
0x35
0x34
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Reserved Board
type
Reserved PA
driving
External
PA
TX Path setting RX Path setting
Reserved Reserve
d
Reserved PA
driving
1:1TX
2: 2TX
1: 1RX
2: 2RX
NIC Configuration 0 Register Bit Fields Description
Offset Field Description
34h
3:0
RX front-end architecture in the system.
0 (0000): Reserved.
1 (0001): 1 RX front-end in the system.
2 (0010): 2 RX front-end in the system.
3 ~ F (0011 ~ 1111): Reserved.
7:4
TX front-end architecture in the system.
0 (0000): Reserved.
1 (0001): 1 TX front-end in the system.
2 (0010): 2 TX front-end in the system.
3~ F (0011 ~ 1111): Reserved.
