2 MT7612 EEPROM Layout
Offset
Default
(hex)
b15 ~b8 b7 ~ b0
00h 7662 Chip ID
02h 0000 EEPROM Version
04h FFFF Mac Address [15:0]
06h FFFF Mac Address [31:16]
08h FFFF Mac Address [47:32]
0Ah 7612 WLAN PCIe Device ID
0Ch 14C3 WLAN PCIe Vendor ID
0Eh 0000 ASIC Reserved
10h 0000 ASIC Reserved
12h 7612 WLAN PCIe subsystem ID
14h 14C3 WLAN PCIE subsystem VendorID
16h 0000 ASIC Reserved
18h 0000 ASIC Reserved
1Ah FFFF ASIC Reserved
1Ch FFFF ASIC Reserved
1Eh FFFF ASIC Reserved
20h FFFF
ASIC Reserved*
22h D837
ASIC Reserved*
24h 009D
For wifi external component
setting
AUX Option
26h 7FFF
ASIC Reserved*
28h 9BFD
ASIC Reserved*
2Ah FFFF
ASIC Reserved*
2Ch FFFF
ASIC Reserved*
2Eh FFFF
ASIC Reserved*
30h FFFF
ASIC Reserved*
32h FFFF
ASIC Reserved*
34h FF22 NIC Configuration 0
36h 2000 NIC Configuration 1
38h FFFF Country Region 2.4G band Country Region 5G band
3Ah 0180 LED Mode Frequency offset
3Ch 0000 LED Reserved
