MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 7 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Offset
Default
(hex)
b15 ~b8 b7 ~ b0
3Eh 0000
LED Reserved
40h 0000
LED Reserved
42h DFFF
NIC Configuration 2
44h 0000
External LNA gain for 5G
Band(CH36~CH64)
External LNA gain for 2.4G Band
46h 0000
2.4G RSSI1 offset 2.4G RSSI0 offset
48h 0000
External LNA gain for 5G
Band(CH100~CH128)
Reserved
4Ah 0000
5G RSSI1 offset 5G RSSI0 offset
4Ch 0000
External LNA gain for 5GBand
(CH132~CH165)
ASIC Reserved*
4Eh 01E0
ASIC Reserved*
ASIC Reserved*
50h 0000
20M/40M BW Power delta for 5G
band
20M/40M BW Power delta for 2.4G band
52h 0000
2G ePA temperature compensation
limit
20M/80M BW Power delta for 5G band
54h 0000
ASIC Reserved* 5G ePA temperature compensation limit
56h
TX0 2.4G PA TSSI offset TX0 2.4G PA TSSI slope
58h
TX0 2.4G TX power offset low
TX0 2.4G TX power (TSSI on)
TX0 2.4G TX ALC CODE (TSSI off)
5Ah
TX0 2.4G TX power offset high TX0 2.4G TX power offset middle
5Ch
TX1 2.4G PA TSSI offset TX1 2.4G PA TSSI slope
5Eh
TX1 2.4G TX power offset low
TX1 2.4G TX power (TSSI on)
TX1 2.4G TX ALC CODE (TSSI off)
60h
TX1 2.4G TX power offset high TX1 2.4G TX power offset middle
62h
TX0 5G PA TSSI offset (Group0) TX0 5G PA TSSI slope(Group0)
64h
TX0 5G TX power offset low(Group0)
TX0 5G TX power(Group0) ( TSSI on )
TX0 5G TX ALC CODE(Group0)( TSSI off )
66h
TX0 5G PA TSSI slope(Group1) TX0 5G TX power offset high(Group0)
68h
TX0 5G TX power(Group1)( TSSI on )
TX0 5G TX ALC CODE(Group1)
( TSSI off )
TX0 5G PA TSSI offset (Group1)
6Ah
TX0 5G TX power offset high(Group1) TX0 5G TX power offset low(Group1)
6Ch
TX0 5G PA TSSI offset (Group2) TX0 5G PA TSSI slope(Group2)
6Eh
TX0 5G TX power offset low(Group2)
TX0 5G TX power(Group2) ( TSSI on )
TX0 5G TX ALC CODE(Group2)( TSSI off )
70h
TX0 5G PA TSSI slope(Group3) TX0 5G TX power offset high(Group2)
72h
TX0 5G TX power(Group3) ( TSSI
on )
TX0 5G TX ALC
CODE(Group3)( TSSI off )
TX0 5G PA TSSI offset (Group3)
74h
TX0 5G TX power offset high(Group3) TX0 5G TX power offset low(Group3)
76h
TX0 5G PA TSSI offset (Group4) TX0 5G PA TSSI slope(Group4)
