2.10 External LNA Gain for 2.4GHz (0x44)
0x44
7
6
5
4
3
2
1
0
Sign
bit
External LNA Gain for 2.4G
External LNA Gain for 2.4GHz Register Bit Fields Description
Offset Field Description
42h
6:0
External LNA gain for 2.4GHz
000000 : 0dB
000001 : 1dB
000010 : 2dB
This value should be reasonable for external component spec.
111111 won’t be invalid.
7
Sign bit
1: plus “ + “
0: minus “ – “
Example:
The default eLNA gain value would be 0x8C and it means “ +12dB”.
2.11 External LNA Gain for 5GHz (0x45/0x49/0x4D)
0x45
7
6
5
4
3
2
1
0
Sign
bit
External LNA Gain for 5G(CH36~CH64)
0x49
7
6
5
4
3
2
1
0
Sign
bit
External LNA Gain for 5G(CH100~CH128)
0x4D
7
6
5
4
3
2
1
0
Sign
bit
External LNA Gain for 5G(CH132~CH165)
External LNA Gain for 5GHz Register Bit Fields Description
Offset Field Description
