MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 12 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Offset Field Description
35h
1:0
external PA
00: 2.4G+5G external PA
01: 5G external PA
10: 2.4G external PA
11: disable
2
External PA current setting –
the IO driving current setting for external PA control
pin
1: 8 mA (default)
0: 16mA
3
Reserved.
5:4
Reserved for define the board type.
7:6
Reserved.
2.4 NIC Configuration 1 (0x36/0x37)
Bit[7:0]=0xFF will be treated as INVALID and used Default Value.
Bit[15:8]=0xFF will be treated as INVALID and used Default Value
0x36
7
6
5
4
3
2
1
0
WPS
PBC
5G side band
for 40M BW
2.4G side band
for 40M BW
Proprietary
Test bit
EXT LNA
5G
EXT LNA
2.4G
Tx temp.
scheme en
HW CTRL
0: off (D)
1: on
0: off(D)
1: on
0: off
1: on(D)
0: off(D)
1: on
0: off
1: on
0: off
1: on
0: off(D)
1: on
0: off(D)
1: on
0x37
7
6
5
4
3
2
1
0
DAC
test bit
BT Coexist
TSSI Power
compensation
en
Antenna Diversity Broadband
EXT LNA
40M BW in
5G band
40M BW in
2.4G band
0: off (D)
1: on
0: off (D)
1: on
0: off(D)
1: on
00: Disable (D) 0: off
1: on
0: on (D)
1: off
0: on (D)
1: off
NIC Configuration 1 Register Bit Fields Description
Offset Field Description
