MEDIATEK MT7612 - 1 General Description; General Descriptions

loginid=danielwu@synnex.com.tw,time=2013-11-28 11:59:39,ip=58.250.71.129,doctitle=MT7612-EEPROM Content v1_02_guideline.pdf,company=Synnex Electronics HK Limited 聯強電子_RLT
MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 5 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
1 General Description
1.1 General Descriptions
The MT7612 EEPROM layout provides configuration for vendor/product ID, SW setting, RF
TX power setting.
Note :
If hardware selects external EEPROM, please follow below EEPROM type.
The following table summarizes EEPROM used in MT7612 series configuration.
EEPROM Type EEPROM size (in byte)
MT7612E
2x2 ac, WIFI @PCIe
93c66 512
MT7612U
2x2 ac, USB3
25060 512
