0x91
TX1 5G TX power Group3 (54M TSSI on )(5480~5570)
TX1 5G TX ALC code Group3 (54M TSSI off )(5480~5570)
0x92
TX1 5G TX power offset low(delta,dB)(CH100 101 104 )
0x93
TX1 5G TX power offset high(delta,dB)(CH106 108 112 114)
0x94
TX1 5G PA TSSI slope (5580~5700)(CH116 120 122 124 128 130 132 136 138 140
144)
0x95
TX1 5G PA TSSI offset (5580~5700)(Group4)
0x96
TX1 5G TX power Group4 (54M TSSI on) (5580~5700)
TX1 5G TX ALC code Group4(54M TSSI off) (5580~5700)
0x97
TX1 5G TX power offset low(delta,dB)(CH116 120 122 124 128)
0x98
TX1 5G TX power offset high(delta,dB)(CH130 132 136 138 140 144)
0x99
TX1 5G PA TSSI slope (5725~5825)(CH149 153 155 156 157 161 162 165)
0x9A
TX1 5G PA TSSI offset (5725~5825)(Group5)
0x9B
TX1 5G TX power Group5 (54M TSSI on )(5725~5825)
TX1 5G TX ALC code Group5 (54M TSSI off )(5725~5825)
0x9C
TX1 5G TX power offset low(delta,dB) (CH149 153 155 156)
0x9D
TX1 5G TX power offset high(delta,dB)(CH157 161 162 165)
2.29 XTAL trim 2 (0x9Fh)
It is the second xtal trim field provided for customer MP site.
1
st
one is 0x3A.
Offset Field Description
9Fh
6:0
Crystal trim value ( Cap ID )
7
Reserved
2.30 TX rate power configuration (0xA0h~0xBFh)
Default value=0x00 (1 step=0.5dBm)
Offset Field Description
A0h
~BFh
5:0 Tx per-rate power setting
7:6
Bit[7] : enable
Bit[6] : 0 : decrease power , 1 :increase power
Offset
Default
Value
Description Bit [5:0]
