MT7612
EEPROM Content
Confidential B
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
A0h 00 2G TX power for CCK 1M/2M TX power setting
A1h
00
2G TX power for CCK 5.5M/11M TX power setting
A2h
00
2G TX power for OFDM 6M/9M TX power setting
A3h
00
2G TX power for OFDM 12M/18M TX power setting
A4h
00
2G TX power for OFDM 24M/36M TX power setting
A5h
00
2G TX power for OFDM 48M/54M TX power setting
A6h
00
2/5G TX power for HT/VHT MCS=0,1 TX power setting
A7h
00
2/5G TX power for HT/VHT MCS=2,3 TX power setting
A8h
00
2/5G TX power for HT/VHT MCS=4,5 TX power setting
A9h
00
2/5G TX power for HT/VHT MCS=6,7 TX power setting
AAh
00
2/5G TX power for HT MCS=8,9 TX power setting
ABh
00
2/5G TX power for HT MCS=10,11 TX power setting
ACh
00
2/5G TX power for HT MCS=12,13 TX power setting
ADh
00
2/5G TX power for HT MCS=14,15 TX power setting
B2h
00
5G TX power for OFDM 6M/9M TX power setting
B3h
00
5G TX power for OFDM 12M/18M TX power setting
B4h
00
5G TX power for OFDM 24M/36M TX power setting
B5h
00
5G TX power for OFDM 48M/54M TX power setting
BEh
00
5G TX power for VHT M8/M9 TX power setting
BFh
00
2G TX power for VHT M8/M9 TX power setting
Example:
If the calibrated TX power =15dBm for 54Mbps = 0x00 (offset = A5h).
Want to set both TX power to 19dBm for MCS 0 & MCS 1 (offset = A6h).
The power difference is 4dBm (19-15). It need to increase register value from 0 to 8 (4dBm =
0.5dBm * 8 step). Setting A6h=0xC8h can meet the power requirement.
Offset Suggest Value Description
0xA0 C3 2.4GHz TX power for CCK 1M/2M(delta,dB)
0xA1 C3 2.4GHz TX power for CCK 5.5M/11M(delta,dB)
0xA2 C4 2.4GHz TX power for OFDM 6M/9M(delta,dB)
0xA3 C4 2.4GHz TX power for OFDM 12M/18M(delta,dB)
0xA4 0 2.4GHz TX power for OFDM 24M/36M(delta,dB)
0xA5 0 2.4GHz TX power for OFDM 48M/54M(delta,dB)
0xA6 C2 2.4/5G TX power for HT MCS=0,1(delta,dB)
0xA7 C2 2.4/5G TX power for HT MCS=2,3(delta,dB)
0xA8 82 2.4/5G TX power for HT MCS=4,5(delta,dB)
0xA9 82 2.4/5G TX power for HT MCS=6,7(delta,dB)
