MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 28 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
0xAA C2 2.4/5G TX power for HT MCS8,9(delta,dB)
0xAB C2 2.4/5G TX power for HT MCS10,11(delta,dB)
0xAC 82 2.4/5G TX power for HT MCS12,13(delta,dB)
0xAD 82 2.4/5G TX power for HT MCS14,15(delta,dB)
0xB2 C2 5GHz TX power for OFDM 6M/9M(delta,dB)
0xB3 C2 5GHz TX power for OFDM 12M/18M(delta,dB)
0xB4 0 5GHz TX power for OFDM 24M/36M(delta,dB)
0xB5 0 5GHz TX power for OFDM 48M/54M(delta,dB)
0xBE 83 TX power for 5GHz VHT MCS=8,9
0xBF 83 TX power for 2.4GHz VHT MCS=8,9
2.31 Reserved for Customer (0x1B8h~0x1BFh)
2.32 Configured 2.4G Channels (0xB0h~B1h)
Default value=0x00, this field is available when 0x39h = 30d. (Configured channel)
7
6
5
4
3
2
1
0
CH8 CH7 CH6
CH5 CH4 CH3 CH2 CH1
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
15
14
13
12
11
10
9
8
Reserve Reserve CH14 CH13
CH12 CH11 CH10 CH9
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
0: off
1: on
For example:
If available channels are 1,2,3 and 5, then
0x39h = 30d, 0x118h = 17h, 0x119h = 00h.
2.33 USB Vendor ID (0x1C2~0x1C3h)
Value
Description
0x0E8D The default Vendor ID for MTK
2.34 USB Product ID (0x1C4h~0x1C5h)
Value
Description
0x7612 The default Product ID for MTK
